Specific to 2x10 or 3x10-speed mountain drivetrains (2x10 for 49.5mm chainline, 3x10 for 51mm chainline)X-Glide technology for fast/smooth shifting and a full range access with little-to-no chain rub in cross-chain combinations
Low-clamp/top-swing (TS), high-clamp/down-swing (DS), or direct-mount (DM) fitment options
Clamp options available to fit 31.8/34.9/38.2mm seat-tubes (separate shim needed for 28.6mm seat tubes) and designed for 66-69 degree chainstay/seat-tube angles
Direct-mount options are chainring size/combination specific and available in three versions: S1 for 42.7mm (2-bolt), S3 for 22.1mm (2-bolt), or H0 (1-bolt + anti-rotation slot)
All-Mountain (AM) offerings optimized for optional 22/36t and/or 24/38t gearing
Compact (CP) version offers enhanced clearance for 27.5/29" frame designs
Configurations for top-pull and/or bottom-pull cable routing depending on specification
Forged alloy clamp/body with a formed steel cage: 130g
Item Specifications
mount: high (DS)
speed: 2x10
capacity: 14T
max: 39T (CP)
color: black/silver
Brand |
SRAM
|
Barcode |
42011610
|
Transmission speeds |
2x10 |
