Brand |
Specialized
|
Weight |
23.79kg (52 lb, 7.2 oz)
|
Frameset/Frame |
Specialized M5 premium alloy, headset adjust, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing
|
Wheels/Spokes |
DT Swiss Industry
|
Wheels/Rims |
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
|
Wheels/Rear tire |
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
|
Wheels/Rear hub |
Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
|
Wheels/Inner tubes |
Standard, Presta Valve
|
Wheels/Front tire |
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
|
Wheels/Front hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
|
Suspension/Rear shock |
FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm
|
Suspension/Fork |
Fox Rhythm 36, S1: 150mm travel, S2-S6: 160mm travel
|
Frameset/Seat binder |
Alloy, 38.6mm
|
E-bike/battery |
Specialized M3-700, Integrated battery, 700Wh
|
E-bike/Wiring harness |
Custom Specialized wiring harness
|
E-bike/UI remote |
Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
|
E-bike/Motor |
Specialized 2.2 Custom Rx Trail Tuned Motor
|
E-bike/Charger |
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
|
Drivertain/Shift levers |
SRAM GX Eagle, trigger, 12-speed
|
Drivertain/Rear derailleur |
SRAM GX Eagle, 12-speed
|
Drivertain/Crankset |
Praxis forged M30, custom offset, 160mm
|
Drivertain/Chainrings |
SRAM X-Sync Eagle, 104 BCD, 32T, steel
|
Drivertain/Chain |
SRAM NX Eagle, 12-speed
|
Drivertain/Cassette |
Sram XG-1275, 12-speed, 10-52t
|
Cockpit/Stem |
Alloy Trail Stem, 35mm bar bore
|
Cockpit/Seatpost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
|
Cockpit/Saddle |
Bridge Comp, Hollow Cr-mo rails, 155/143mm
|
Cockpit/Handlebars |
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
|
Cockpit/Grips |
Specialized Trail Grips
|
Brakes/Rear brake |
SRAM Code R, 4-piston caliper, hydraulic disc, 200mm
|
Brakes/Front brake |
SRAM Code R, 4-piston caliper, hydraulic disc, S1-S3: 200mm, S4-S6: 220mm
|
