| Brand |
Specialized
|
| Frameset/Frame |
All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm
|
| Weight |
24.41 kg (53 lb, 13.0 oz)
|
| Item group |
LEVO
|
| Color |
GLOSS ORANGE TINT OVER SILVER DUST / DARK NAVY
|
| Year |
2026
|
| Wheels/Spokes |
DT Swiss Industry
|
| Wheels/Rims |
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
|
| Wheels/Rear tire |
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
|
| Wheels/Rear hub |
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
|
| Wheels/Inner tubes |
Standard, Presta valve
|
| Wheels/Front tire |
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
|
| Wheels/Front hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
|
| Suspension/Rear shock |
FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment
|
| Suspension/Fork |
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 160mm of travel
|
| Frameset/Seat binder |
Alloy, 38.6mm
|
| E-bike/battery |
840Wh battery
|
| E-bike/UI remote |
All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app
|
| E-bike/Motor |
All New Specialized 3.1 Motor, 101Nm torque, 666W power
|
| E-bike/Charger |
Specialized 4amp charger
|
| Drivertain/Shift levers |
SRAM AXS POD Controller
|
| Drivertain/Rear derailleur |
SRAM S1000 Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).
|
| Drivertain/Crankset |
SRAM S1000 Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm
|
| Drivertain/Chainrings |
SRAM T-type ring, 34T, 104 BCD, steel
|
| Drivertain/Chain |
SRAM GX Eagle Transmission Flattop Chain
|
| Drivertain/Cassette |
SRAM XS-1270 Transmission Cassette, 12spd, 10-52t
|
| Cockpit/Stem |
Alloy Trail Stem, 35mm bar bore
|
| Cockpit/Seatpost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
|
| Cockpit/Saddle |
Bridge Comp, Hollow Cr-mo rails
|
| Cockpit/Handlebars |
Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S2: 30mm rise, 780mm width, S3-S5: 40mm rise 800mm width
|
| Cockpit/Grips |
Specialized Trail Grips
|
| Brakes/Rear brake |
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Rotor
|
| Brakes/Front brake |
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Rotor
|
| Accessories/Swat |
SWAT internal downtube storage
|
